Basic Info.
Model NO.
MUSE
Wattage
251-350W
Battery Voltage
36V
Battery Type
Lithium Battery
Wheel Size
28"
Motor
Brushless
Frame Material
Aluminum Alloy
Certification
CE, EEC, EN15194, ISO, CQC, EPA, COC, DOT
Folded
Unfolded
Max Speed
20-40km/h
Range per Power
>60km
Transport Package
Carton
Specification
1500*250*890 mm
Trademark
OVERFLY
Origin
China
HS Code
8711600010
Production Capacity
50000PCS/Year
Product Description
| FRAME & SUSPENSION | |||
| FRAME | SIZE | TYP | FRONT FORK/REAR SHOCK |
| 6061 Aluminum Alloy | 28" | Step Through | Suntour Lockable XCM-ATB Suspension Fork with 100mm travel |
| E-BIKE SYSTEM | |||
| MOTOR | BATTERY | DISPLAY | CHARGER |
| Ananda M81 36V 250W | 36V 13AH - 468WH | LCD color screen,USB/bluetooth optional | 2A |
| MAX SPEED | RANGE | WALK ASSISTANCE | CHARGING TIME |
| 25km/h, EU standard | >60km | 6km/h | 3-5 hours |
| DRIVETRAIN & BRAKES | |||
| BRAKE SYSTEM | REAR DERAILLEUR | SHIFTERS | FREEWHEEL |
| F: TEKTRO hydraulic disk brake R: TEKTRO hydraulic disk brake | Shimano ALTUS 8-speed | Shimano 8-speed | 11-34T |
| CRANKSET | CHAIN/BELT | ||
| 38T, with cover | KMC e8 | ||
| COCKPIT | |||
| HEADSET | STEM | HANDLEBAR | GRIPS |
| Semi-hidden | ZOOM Height Adjustable, 6061 aluminum alloy | 6061 aluminum alloy, 610mm | VELO, VLG-1389 Comfort |
| WHEELS | |||
| RIMS | TYRES | FRONT WHEEL HUB | REAR WHEEL HUB |
| 36H*13G, double wall | CST 28*2.0" | Disc Brake Hubs | Cassette Disc Brake Hubs |
| FINISHING KIT | |||
| SADDLE | SEAT POST | PEDALS | KICKSTAND |
| Selle Royal , FREEWAY | 30.4*350mm Aluminum alloy | WELLGO | With |
| FRONT LIGHT | REAR LIGHT | MUDGUARDS | CARRIER |
| SPANNIGA Front lights with wires(50LUX) | Rear light with battery | Plastic | 6061 Aluminum alloy |
This e-bike is equipped with a 36V 13Ah high-capacity battery, ensuring a longer range, which meets the needs of daily riding.
A suspension fork offers a smoother and more comfortable riding experience.
The 8-speed gear system allows riders to select the appropriate speed according to different road conditions and riding needs, enjoying a more diverse riding experience.
